HYDRAULIC SYSTEM RT530E-2 SERVICE MANUAL
2-24 Published 4-22-15, Control # 556-00
Item Description
1 Procedure A - Telescope Extend Port Relief
2 Procedure A - Load Sense Relief Valve
3 Procedure A - Telescope Retract Port Relief
4 Gauge Port 7
5 Pilot End Cap GPD Lift Down
6 Pilot End Cap GPC Telescope Retract
7 Pilot End Cap GPA Main Hoist Up
8 Pilot End Cap GPB Aux Hoist Up
3
FIGURE 2-10
2
1
4
6
5
7
8
