Published 4-22-15, Control # 556-00
2-29
RT530E-2 SERVICE MANUAL
HYDRAULIC SYSTEM
2
GROVE
2
4
5
3
1
6725
CARRIER
FIGURE 2-14 continued
6
7
Item
Description
1
Front Outrigger Control Manifold
2
Outrigger/Rear S
teer V
alv
e
3
Differential Lock V
alve
4
Park Brake Range Shif
t V
alve
Item
Description
5
Axle Lockout V
alve
6
Rear Outrigger Control manifold
7F
r
a
m
e
Reference
Only
62
64
