OPERATING CONTROLS AND PROCEDURES RT530E-2 OPERATOR’S MANUAL
3-44 Published 5-3-2016, Control # 555-02
Low Brake Pressure
Low Steering Fluid Pressure
Main Hoist Status
Main Hoist Disabled
Main Hoist Enabled
Main Hoist Raise
Main Hoist Not In Use
Main Hoist Lower
Marker/Position/Side Light
Rear Wheels Not Centered
Oil Feed Filter Contaminated
Outrigger Button
Outrigger Front Left
Outrigger Front Right
Outrigger Group
Outrigger Rear Left
Outrigger Rear Right
Park Brake
Symbol Description
Reference Only
