Published 5-3-2016, Control # 555-02 4-13
RT530E-2 OPERATOR’S MANUAL SET-UP AND INSTALLATION PROCEDURES
4
GROVE
Stowing
1. With crane set up on outriggers, fully retract the boom
and swing to over-the-front.
2. Lower the boom to minimum elevation.
3. Remove the cable retainer pin from the boom extension
tip and the mast assembly. Remove the hoist cable from
the sheaves. Install the cable retainer pins.
4. Remove the mast assembly retainer pin and the pin
securing the mast assembly in the upright position. Lay
the mast assembly over to the stowed position. Insert
the pins securing the mast to the base section.
5. Attach a length of rope to the boom extension tip.
6. Disconnect RCL cable:
a. Remove connector from junction box on boom
nose.
b. Install dummy plug in junction box.
c. Route cable to and attach to boom extension
7. Raise the boom to horizontal.
8. Extend the boom approximately 20 to 25 in (51 to
64 cm). Make certain that the boom extension stowage
lugs will line up in front of the guide pins and ramp on the
stowage brackets when the boom extension is
positioned to the side of the boom.
9. Ensure the hitch pin and clip pin are removed from the
rear stowage bracket (Figure 4-12) (Detail A).
10. Extend the boom extension alignment jack (Figure 4-11)
until the bottom left side attachment pin is free. Remove
the bottom left side boom extension clip pin and
attachment pin.
11. Release pressure on the boom extension alignment
jack. Completely retract the jack.
12. Remove the top left side attachment pin and clip pin from
the upper anchor and attachment fittings of the boom
nose.
13. Using the rope attached to the tip of the boom extension,
manually swing the extension to the side of the boom.
14. Align the stowage lugs on the boom extension with the
guide pins and ramp on the stowage brackets and fully
retract the boom.
15. Install the hitch pin and clip pin securing the boom
extension to the rear stowage bracket (Figure 4-12)
(Detail A).
16. Remove the attachment pins and clip pins from the
anchor and attachment fittings on the right side of the
boom nose and stow them in the base of the boom
extension. Stow left side attachment pins and clips in
outside attachment fitting on swingaway.
17. On the rear stowage bracket, remove the pin securing
the sliding support in the “OUT” position. Push in on the
handle to push the swingaway against the rear of the
boom and disengage the swingaway anchor fittings from
the boom nose attachment lugs. Install the retainer pin
securing the sliding support in the “IN” position.
18. Rig the boom nose and hoist cable as desired and
operate the crane using normal operating procedures.
Setting the Offset
1. Extend and set the outriggers. Swing the boom over to
the front of the crane.
2. To set the offset from zero degrees (0°) to thirty degrees
(30°), perform the following:
a. Slowly lower the boom until the tip of the swingaway
is on the ground and the pressure on the offset pin is
relieved.
b. Remove the lock pin, two washers, and offset pin.
c. Slowly elevate and telescope the boom at the same
time until the offset shaft takes the full load of the
swingaway.
3. To set the offset from thirty degrees (30°) to zero
degrees (0°), perform the following:
DANGER
When stowing the boom extension, ensure that all
personnel and equipment are kept clear of the swing path.
CAUTION
Do not allow the boom extension to slam into the stowage
bracket when swinging into the stowed position.
CAUTION
The mast assembly must be positioned on top of the base
section before attempting to offset the swingaway to 30
degrees. Failure to do so can cause damage to the mast
and/or swingaway adapter.
CAUTION
Do not overload the swingaway or the attachment points
when lowering the boom.
Reference Only
