Published 5-3-2016, Control # 555-02 6-1
RT530E-2 OPERATOR’S MANUAL MAINTENANCE CHECKLIST
SECTION 6
MAINTENANCE CHECKLIST
SECTION CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Daily or 10 Hour Check List. . . . . . . . . . . . . . . . . . 6-1
Weekly or 50 Hour Check List . . . . . . . . . . . . . . . . 6-2
GENERAL
This section contains a list of daily inspection and
maintenance checks. Performing the checks will help
maintain the safety, dependability, and productivity designed
into your crane.
Refer to your Inspection and Lubrication Service Log for
further requirements.
INSTRUCTIONS
Refer to your Service Manual for specific maintenance and
adjustment procedures.
Refer to Section 5 - Lubrication (in this Operator Manual) for
lubrication intervals, types of fluids and lube point locations.
Daily or 10 Hour Check List
1 Operator Manual: Is item properly installed on machine?
2 Signal and Running Lights and Horn: Check for cracked or broken glass. Check for proper working order
3 Backup Alarm: Check for proper operation while operating machine
4 Gauges and Instruments: Check for proper working order. Check for proper reading while operating engine;
Check for proper operation while operating machine
5 Brakes (Swing, Foot and Parking): Check for proper working order. Check for proper operation while operating
machine
6 Boom Angle Indicator: Check for proper operation while operating machine
7 Rated Capacity Limiter: Check for proper operation while operating machine. Check connectors and wiring for
proper alignment and insulation
8 Antitwo-Block (A2B) Electrical and Hydraulic: Check for proper operation while operating machine. Check
connectors and wiring for proper alignment and insulation
9 Brakes and Air System (if equipped): Check for proper working order. Check for proper operation while
operating machine. Drain moisture
10 Tires: Check for proper inflation/pressure. Check for excessive wear. Check for excess dirt, grease or foreign
matter
11 Hydraulic Tank: Check for proper service/level. Check for excess dirt, grease, or foreign matter
12 Hydraulic Oil Filter: Check for proper service/level
13 Wire Rope: Check for damaged, frayed, or broken strands.
14 Hoists: Is item properly installed on machine? Check for excess dirt, grease, or foreign matter. Check for proper
operation while operating machine
15 Boom and Attachments: Is item properly installed on machine? Check for excess dirt, grease, or foreign matter;
Check for proper operation while operating machine
16 Engine: Check for proper service/level. Check for excess dirt, grease, or foreign matter
17 Transmission/Torque Converter: Check for proper service/level
18 Cooling System: Check for proper service/level. Check for cracks or leaks
Reference Only
