Manitowoc Grove RT530E-2 - Outriggers

LUBRICATION RT530E-2 OPERATOR’S MANUAL
5-14 Published 5-3-2016, Control # 555-02
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Outriggers
18
Outrigger Beams
(Outside)
Figure 5-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
--- 50 hours or 1 week
Brush lubricant on
bottom of outrigger
beams
19
Jack Cylinder
Support Tubes
Figure 5-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
--- 50 hours or 1 week
Brush lubricant on
OD of jack cylinder
barrel and wear
band before
installing jack
cylinders
51
Jack Cylinder
Barrels
Figure 5-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
--- 50 hours or 1 week
Brush lubricant on
OD of jack cylinder
support tubes (4)
places before
installing jack
cylinders
54
Outrigger Beams
(Inside)
Figure 5-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
--- 50 hours or 1 week
Brush lubricant on
inside bottom of
outrigger beams
where beam
extension cylinder
guide supports
travel
