RT530E-2 OPERATOR’S MANUAL OPERATING CONTROLS AND PROCEDURES
Figure 3-13 Item Numbers
Item Description
1 Transmission Temperature
2 Fuel Level
3 Battery Voltage
4 Engine Speed (Tachometer)
5 Engine Coolant Temperature
6 Diesel Exhaust Fluid (Optional)
7 Direction/Gear Number
8 Engine Warm-up Indicator (Wait-to-start)
9 Park Brake
10 Emergency Stop
11 Marker/Position/Side Light
12 Rear Wheels Not Centered
13 Four-Wheel Drive Indicator
14 Differential Lock Indicator (Optional)
15 Cold Temperature Warning (Optional)
16 Engine Stop
17 Engine Warning Indicator
18 Hydraulic Oil Temperature
19 Low Brake Pressure
20 System Fault
21 Boom Angle Too Low (Optional)
22 Third Wrap Indicator (Optional)
23 Low Steering Pressure (Optional)
24 Regen Needed (Optional)
25 Regen Inhibited (Optional)
26 High Exhaust Temperature (Optional)
27 Work Range Limiter Indicator (Optional)
28 Active Screen Indicator
29 Alerts Area
30 Status Bar
31 Status Area
