INTRODUCTION RT600E OPERATOR MANUAL
LIST OF SPECIFICATIONS
General
Model . . . . . . . . . . . . . . . . . . . . . . . RT600E Series
Rated Capacity . . . . . . . . . . See Load Chart in cab
Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 x 4 x 4
Gross Weight . . . . . . . . . . . . . . . . See Axle Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . Distribution Table
Dimensions
NOTE: Dimensions listed are for a crane with all
components fully retracted in the travel mode with
23.5 x 25 tires.
Wheelbase . . . . . . . . . . . . . . . . . 3759 mm (148 in)
Overall Crane Length . . . . . . . .12,776 mm (503 in)
Overall Crane Width . . . . . . . . . . 3022 mm (119 in)
Overall Crane Height . . . . . . . .3503 mm (137.9 in)
Tail-Swing . . . . . . . . . . . . . . . . . . 3912 mm (154 in)
Outrigger Spread
Retracted . . . . . . . . . . . . . .2883 mm (113.5 in)
Mid Extend . . . . . . . . . . . . . . 4877 mm (192 in)
Fully Extended . . . . . . . . . . . 6858 mm (270 in)
Capacities
Fuel Tank . . . . . . . . . . . . . . . . . . . . . .220 l (58 gal)
Coolant System. . . . . . . . . . . . . . . . . . . See Engine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications
Engine Lubrication System . . . . . . . . . . See Engine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications
Hydraulic Tank (Reservoir Capacity)
Total . . . . . . . . . . . . . . . . . . . . . .564 l (149 gal)
at Full Level . . . . . . . . . . . . . . . .507 l (134 gal)
at Add Level . . . . . . . . . . . . . . . .477 l (126 gal)
Expansion Space . . . . . . . . . . . . . . 57 l (15 gal)
Hoists . . . . . . . . . . . . . . . . . . . . . . . .14.7 l (15.5 qt)
Swing Gearbox . . . . . . . . . . . . . . . . . . 5 l (5-1/4 qt)
Axle Planetary Ends . . . . . . . . . . . . . . .1.7 l (3.5 pt)
Axle Differentials . . . . . . . . . . . . . . . . . . 9.5 l (20 pt)
Transmission (includes Torque Converter)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 l (27 qt)
Torque Converter
Stall Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . 1.943:1
Charge Pump Capacity. . . . . . . . 76 l/min (20 gpm)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . @ 2000 rpm
Transmission
Gear Ratios
Forward
1st . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8.75
2nd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.09
3rd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.32
4th . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.93
5th . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.30
6th . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.76
Reverse
1st . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8.75
2nd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.32
3rd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.30
Engine
Cummins QSB6.7
Type . . . . . . . . . . . . .6 cycle, Diesel, Turbocharged
Number of Cylinders . . . . . . . . . . . . . . . . . . . . . . . 6
Gross installed power@rpm
. . . . . . . . . . . . . . . . .179 kW (240 hp) @ 2500 rpm
Lube Amount (w/o filter) (full) . . . . . . 17.5 l (18.5 qt)
Coolant System . . . . . . . . . . . . . . . . . . . 34 l (36 qt)
Axles
Total Ratio. . . . . . . . . . . . . . . . . . . . . . . . . . . 24.6:1
Carrier Ratio . . . . . . . . . . . . . . . . . . . . . . . . 6.833:1
Planetary Ratio . . . . . . . . . . . . . . . . . . . . . . . 3.60:1
Brakes
Type . . . . . . . . . . . . . . . . . . . . . . . . . Hydraulic Disc
Size. . . . . . . . . . . . . 470 x 16 mm (18.5 x 0.625 in)
Wheels And Tires
Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Torque. . . . . . . . . . . 461 to 488 Nm (340 - 360 ft lb)
Tire Size
Standard . . . . . . . . . . . 23.5 x 25, 24 ply rating
Optional . . . . . . . . . . . . . 23.5R25, 24 ply rating
For roading and lifting pressures, refer to the Load
Chart Book in the cab.
Swing Gearbox
Reduction Ratio . . . . . . . . . . . . . . . . . . . . . . . . 36:1
Output Torque. . . . . . . . . . . . . . . . . . . . 45,000 in lb
Boom
Length. . . . . . . . 10.06 to 32.0 meters (33 to 105 ft)
Power . . . . . . . . . . . . . . . . . . 4 Section, Full Power
Elevation . . . . . . . . . . . . . . . . . . . -2 to +78 degrees
Extensions
Fixed* . . . . . . . . . . . . . . . . . .8.8 meters (29 ft)
Telescope* . . . . 8.8 or 15.5 meters (29 or 51 ft)
*Extensions are offsettable at 0, 25, or 45 degrees.
Swivel Assembly
Electrical . . . . . . . . . . . . . . . . . . . . . . .20 Slip Rings
Hydraulic. . . . . . . . . . . . . . . . . . . . . . . . . . . 10 ports
R134A Refrigerant . . . . . . . . . . . . . . . . . . . . 2 ports
Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 ports
Hydraulic Pumps
Pump #1
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Gear
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Output - @ 2781 rpm w/no load
Section 1 . . . . . . . . . . . . . . 207 l/min (55 gpm)
Section 2 . . . . . . . . . . . . . . . 79 l/min (21 gpm)
Pump #2
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Gear
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Output - @ 2698 rpm w/no load
Section 1 . . . . . . . . . . . . . . 121 l/min (32 gpm)
