RT600E OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
Published 05-02-2018 Control # 088-10
Auxiliary Hoist Speed Selector Switch
(Optional)
The auxiliary hoist speed selector switch (16) is located on
the left armrest. It is a three position (HI/LO/OFF) switch. LO
is low operating speed position. Put the switch to HI to
energize a solenoid controlled valve on the hoist motor to
change its displacement to make it run faster. When the
switch is in the HI or the LO position, the amber LED square
in the switch will be illuminated. The speed selector switch
must be in the HI or the LO position before the hoist can be
operated. Putting this switch at OFF prevents the operator
from accidentally activating the hoist.
227415
