3-11
RT600E OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Published 05-02-2018 Control # 088-10
GROVE
Low Brake Pressure Indicator
The LOW BRAKE PRESSURE indicator (28) is located on
the center of the console on the indicator light alert display. It
illuminates red and a warning buzzer is activated when the
pressure in the dual accumulator charge valve falls below
normal operating requirements.
Park Brake Control Switch
The PARK BRAKE control switch (29) is located on the left
side of the front console. This two-position rocker switch
(ON/OFF) is used to apply and release the parking brake on
the transmission. The red square LED on the switch is
illuminated when the pressure switch in the brake release
system is activated. The switch is guarded to prevent
accidental activation.
Turntable Lock Control (Pin Type)
The pin swing lock control handle (30) is located beside the
front console on the right side of the cab. The purpose of the
pin swing lock is to lock the superstructure in position directly
over the front for pick and carry loads. When the control
handle is pushed down and the superstructure is directly
over the front, the swing lock pin drops into the socket on the
carrier frame, locking the superstructure in place. When the
control handle is pulled up, the pin is pulled out of the socket,
unlocking the superstructure.
360 Degree Swing Lock Control (Positive
Lock Type) (Optional)
The 360 degree swing lock control lever (optional) (31) is
located on the right side of the operators seat next to the
control armrest. The purpose of the swing lock is to secure
the superstructure in position at any point in its 360 degree of
rotation. The lock is engaged when the control lever is
pushed down and disengaged when the control lever is
pulled up.
Rated Capacity Limiter (RCL) and Work Area
Definition System Control Panel
The RCL and Work Area Definition System control panel (32)
is located on the right side of the front console. It maintains
the controls and indicators for the crane’s Rated Capacity
Limiter (RCL) System and Work Area Definition System.
Refer to the RCL Manual for detailed information.
Low Steer Pressure Indicator (CE Units)
The LOW STEER PRESSURE indicator (33) is located on
the center of the front console on the indicator light display. It
illuminates red when the hydraulic pressure is low.
Transmission Service Indicator (XMSN)
The TRANSMISSION SERVICE indicator (34) is located on
the center of the console on the indicator light display. It
illuminates red and a warning buzzer is activated during low
transmission oil pressure or high transmission oil
temperature conditions.
Headlights Switch
The HEADLIGHTS switch (35) is located on the left side of
the front console. This two-position ON/OFF rocker switch
controls operation of the instrument lights, switch LEDs, and
the marker lights on the front, rear, and side of the crane.
When the switch is in the ON position, the square amber
LED on the switch is illuminated.
Work Light Switch
The WORK LIGHT switch (36) is a two-position ON/OFF
rocker switch, located on the left side of the front console.
The switch controls the operation of the crane’s work light
(69). When the switch is in the ON position, the square
amber LED on the switch is illuminated.
Cab Circulating Fan
The cab circulating fan (37) is located on a mounting bracket
on the left front side of the cab, above the window frame. A
swivel allows the fan to be rotated and a switch on the fan
base controls the fan. The switch has a HIGH setting, a LOW
setting, and an OFF position.
Horn
The horn button (38) is a push-button type switch located in
the center of the steering wheel. Depressing the horn button
energizes a relay that sounds the horn on the cab exterior.
Hazard Lights Switch
The HAZARD lights switch (39) is located on the left side of
the front console. The switch is a two-position ON/OFF
rocker switch that causes the four turn signal lights to flash at
the same time when the switch is positioned to ON. When
the switch is positioned to ON, the square amber LED on the
switch is also illuminated.
Boom Light Switch (Optional)
The BOOM LIGHT switch (optional) (40) is located on the left
side of the front console. This two-position ON/OFF rocker
switch controls operation of the boom flood lights. When the
switch is in the ON position, the square amber LED on the
switch is illuminated.
227415
