OPERATING CONTROLS AND PROCEDURES RT600E OPERATOR MANUAL
3-30
Published 05-02-2018 Control # 088-10
Crane Functions
Setting The Outriggers
1. Engage the Parking Brake.
NOTE: The Parking Brake must be engaged to enable
outrigger functions.
2. Position the outrigger floats directly out from each
outrigger to where the outriggers will be properly
extended.
3. If extending the outrigger to the mid-extend or fully
extended position, depress the desired Extension
Switch on the Outrigger Selector Panel and hold the
Outrigger Extension/Retraction Switch to EXTEND. The
appropriate outrigger beam begins to extend. Refer to
Engaging The Mid-Extend Lock Pin, page 3-31 if the
crane is to be operated with any outrigger at the mid-
extend position.
NOTE: More than one outrigger beam can be extended at
a time. However, to ensure that each outrigger is
fully extended, repeat step 3 for each outrigger
after a multi-outrigger extension.
4. After deploying the four outrigger beams to one of the
three proper positions (fully retracted, mid-extend, fully
extended), depress the desired Jack Switch on the
Outrigger Selector Panel and hold the Outrigger
Extension/Retraction Switch to EXTEND. The
appropriate jack begins to move.
Extend each jack, positioning the float as necessary,
until the locking levers of the float engage the jack
cylinder barrel.
NOTE: More than one jack can be extended at a time.
5. Extend the front jacks approximately 3 to 4 in (8 to 10
cm).
6. Extend the rear jacks approximately 3 to 4 in (8 to 10
cm).
NOTE: If crane is equipped with tilting cab, ensure cab is in
the lowered position before leveling machine.
7. Repeat step 4 until all wheels are clear of the ground
and the crane is level as indicated by the bubble level
indicator located on the right side of the cab.
NOTE: If it is suspected that the bubble level indicator is
out of adjustment, verify and adjust the bubble level
using the procedures under Bubble Level
Adjustment, page 3-28.
DANGER
Death or serious injury could result from improper crane
setup on outriggers.
The outriggers must be properly extended and set and the
crane level before any other operation of the crane on
outriggers is attempted.
When operating the crane on outriggers, the outriggers
should always be fully extended or locked in the mid-
extend position, depending on the load chart being used.
CAUTION
Possible Equipment Damage!
Always depress one of the outrigger/selector switches
before positioning the outrigger extension/retraction
switch to extend or retract. Failure to do this may cause a
hydraulic lock against the individual solenoid valves,
preventing them from opening.
WARNING
Electrocution Hazard!
To avoid death or serious injury, keep all parts of this
machine, the rigging, and materials being lifted at least 20
feet away from electrical power lines and equipment.
WARNING
Tipping Hazard!
All four outrigger beams must be deployed to one of three
positions before beginning operation, which include fully
retracted, mid-extend, or fully extended; do not operate
the crane with the outriggers in any other position.
WARNING
Tipping Hazard!
The mid-extend outrigger beam lock pin must be engaged
before operating on any beam from the mid-extend
position.
For cranes not equipped with an Outrigger Monitoring
System, the operator must select the proper load chart
and RCL program for the outrigger position selected.
227415
