5-27
RT600E OPERATOR MANUAL LUBRICATION
Published 05-02-2018 Control # 088-10
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Hoist
90 Main Hoist Figure 5-10
EPGL-5H
EPMP Gear
Lube
A6-829-006240
11.3 l (12
qt)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass
91 Auxiliary Hoist Figure 5-10
EPGL-5H
EPMP Gear
Lube
A6-829-006240
11.3 l (12
qt)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass
92 Main Hoist Figure 5-10
AGMA
Extreme
Pressure Gear
Lubricant
A6-829-100213
14.7 l (15.5
qt)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass
93 Auxiliary Hoist Figure 5-10
AGMA
Extreme
Pressure Gear
Lubricant
A6-829-100213
14.7 l (15.5
qt)
• Check and fill every
50 hours or weekly
• Drain and fill every
1000 hours or 12
months
Oil level must be
visible in the sight
glass
NOTE: Line up the Fill/Drain Plug with the top cutout hole (A). Verify hoist is level side to side. Place a level along the a tie
rod and confirm the bubble is centered. Let hoist sit idle for 20 minutes for an accurate reading. Oil should be
visible in sight glass. Level of oil is acceptable if it is at least 1/16” down from top or up 1/16” from the bottom of the
sight glass. Hoist and oil temperature should be in the 70°F +/- 20°F range. If oil temperature is outside this range,
allow for a higher oil level reading if hotter or a lower oil level reading if colder. Oil escaping from vent plug is an
indication the hoist may be overfilled. If hoist is over filled move the Fill/Drain Plug to the lower cutout hole (B) and
drain until oil level falls within the sight glass.
227415
