BOOM RT765E-2 SERVICE MANUAL
4-4
Published 9-04-2014, Control # 422-08
Item Description
1 Fly Section
2 Outer Mid Section
3 Inner Mid Section
4 Base Section
5 Upper Telescope Cylinder
6 Lower Telescope Cylinder
7 Extend Sheave Mounting Assembly
8 Upper Cylinder Support Foot
9 Wear Pad
10 Extend Sheave Assembly
11 Extend Sheave Shaft
12 Extend Sheave Shaft Plate
13 Cable Retainer
14 Extend Cables
15 Retract Cables
16 Skid Pad
17 Lower Cylinder Mount
18 Lower Cylinder Mount Shaft
19 Upper Cylinder Support
20 Wear Pad Support
21 Wear Pad
22 Cable Rollers
Item Description
23 RCL Cable Mounting Angles
24 Upper Wear Pad Keeper Plates
25 Lower and Side Wear Pad Keeper Plates
26 Upper Boom Nose Sheaves
27 Lower Boom Nose Sheaves‘
28 Cable Retainer Pins
29 Sheave Shaft/Boom Extension Anchor Lugs
30 Anti-Rotation Guide BLock
31 Shim
32 Bottom Wear Pads and Shim
33 Rear Side Wear Pads
34 Top Rear Wear Pads
35 Retract Cable Sheave
36 Retract Cable Sheave Shaft
37 Retract Cable Sheave Mount
38 Upper Cylinder Barrel Mounting Plate
39 Upper Cylinder Rod Mounting Plate
40 Lower Cylinder Barrel Mounting Plate
41 Lower Cylinder Rod Mounting Plate
42 Pusher Rod
43 Cam Operated Check Valve
44 Boom Extension Pusher Bar
