2-21
GROVE
RT765E-2 SERVICE MANUAL HYDRAULIC SYSTEM
2
Published 9-04-2014, Control # 422-08
Pump Disconnect Assembly
Disassembly
1. Remove pipe plug and plugs from their holes in the
housing.
2. Remove roll pin to free shifter assembly from shaft.
Remove shifter assembly.
3. Remove roll pin to free collar from shaft. Remove collar
and shaft and attached parts from housing.
4. Remove roll pin to free handle from shaft. Remove
handle. Remove shifter lock from handle.
5. Remove oil seals from housing.
Assembly
1. Install two oil seals into holes in housing.
2. Pin shifter assembly in housing with shaft.
3. Pin collar to shaft with roll pin.
4. Install shifter lock on handle.
5. Install handle on free end of shaft. Pin handle to shaft
with roll pin.
6. Adjust shifter lock so handle can lock it into the IN detent
position and into the OUT detent position. Then place
handle at the OUT position.
7. Pin shifter assembly to shaft with roll pin.
8. Verify shifting parts shift properly. In other words, verify
the handle moves the shifter assembly in and out, the
shifter lock locks properly at each position, and the shaft
and attached parts pivot without binding.
9. Repeat above step with splined coupler in place.
10. Install pipe plug and plugs in their holes in the housing.
Item Description
1 Engine
2 Transmission
3 Hydraulic Pump No. 3
4 Hydraulic Pump No. 1
5 Hydraulic Pump No. 2
Reference Only
