LUBRICATION RT765E-2 SERVICE MANUAL
9-22
Published 9-04-2014, Control # 422-08
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Boom (continued)
75
Boom Section
Front Wear Pads
Figure 9-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Thoroughly
coat all
areas the
wear pad
moves on
50 hours or 1 week
Brush grease on the
outside of sections
1, 2, & 3 in the area
that the front wear
pads move on
NOTE: Lubricate items more frequently than interval indicated in table if environmental conditions and/or operating
conditions necessitate.
76
Extend Cable
Sheaves
Figure 9-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Until
grease
extrudes
250 hours or 3 months
• 1 grease fitting
• Extend boom for
access through
holes
NOTE: Lubricate items more frequently than interval indicated in table if environmental conditions and/or operating
conditions necessitate.
77
Retract Cable
Sheaves
Figure 9-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Until
grease
extrudes
250 hours or 3 months 2 grease fittings
78 Boom Pivot Shaft Figure 9-8
Until
grease
extrudes
250 hours or 3 months 2 grease fittings
79
Boom Extension
Sheave
Figure 9-8
Until
grease
extrudes
250 hours or 3 months 1 grease fitting
81
Upper Boom
Nose Sheave
Figure 9-8
Until
grease
extrudes
250 hours or 3 months
2 grease fittings
(1) per sheave
82
Lower Boom
Nose Sheave
Figure 9-8
Until
grease
extrudes
250 hours or 3 months 5 grease fittings
83
Auxiliary Boom
Nose Sheave
Figure 9-8
Until
grease
extrudes
250 hours or 3 months 1 grease fitting
Reference Only
