HYDRAULIC SYSTEM RT765E-2 SERVICE MANUAL
2-60
Published 9-04-2014, Control # 422-08
8020-2
Item Description
1 Main Directional Control Valve
2 Center Mid/Outer Mid Tele Extend Circuit
3 Inner Mid Tele Extend Circuit
4 Case Drain Manifold
5 Tele Cyl Charge Valve Manifold
6 Swivel
7 Pressure Reducing Sequence Valve
5
3
4
1
2
7
6
FIGURE 2-35
Reference Only
