INTRODUCTION RT765E-2 SERVICE MANUAL
1-6
Published 9-04-2014, Control # 422-08
Rem: Removable Counterweight System -
Cwt Weldment only
-138.34 (-54.66) -6729 (-14835) 2299 (5068) -9028 (-19903)
Sub: Add’l Hoist Access Platform Weight w/
Removable Counterweight
-84.18 (-213.82) 44 (20) -23 (-10) 67 (30)
Sub: Removable Cwt add'l weight (not part
of cwt inst.)
-139.70 (-55.00) 49 (107) -17 (-37) 65 (144)
Sub: Cwt Stand on Front O/R Box w/
Removable Counterweight
553.72 (218.00) 53 (117) 72 (159) -19 (-42)
Sub: Aux Hoist (replace IPO Cwt with Aux
Hoist and Cable)
-134.62 (-53.00) 264 (583) -88 (-193) 352 (776)
Rem: Main Hoist Cable (153 m (502 ft) of
3/4 in 35x7)
-66.04 (-26.00) -278 (-612) 45 (99) -323 (-711)
Rem: Aux Hoist Cable (153 m (502 ft) of 3/4
in 35x7)
-149.86 (-59.00) -278 (-612) 103 (226) -380 (-838)
Sub: Optional Cable on Main Hoist (199 m
(653 ft) of 3/4 in 35x7)
-66.04 (-26.00) 84 (185) -14 (-30) 98 (215)
Sub: Tier 3 Engine -170.18 (-67.00) -216 (-477) 91 (200) -307 (-677)
Sub: Kaydon Bearing 208.28 (82.00) 57 (126) 29 (65) 28 (61)
Description
CG From Rear
Axle cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Reference Only
To Next Page
