HYDRAULIC SYSTEM RT765E-2 SERVICE MANUAL
2-52
Published 9-04-2014, Control # 422-08
1
3
2
4
5
6
7
8
1
3
2
4
5
6
7
8
6697-2
6697-1
Hydraulic Schematic
FIGURE 2-30
Item Description
1 Port P - Pressure
2 Port T - Tank
3 Port A - Range Shift Actuator
4 Port B - Range Shift Actuator
Item Description
5 Port PB - To Park Brake
6 Solenoid Valve - Range Shift
7 Solenoid Valve -Park Brake
8 Pressure Switch
Reference Only
