170 Part Number 80-1505-3 6/11
Feel temperature of Liquid Line
at rear of Head Section
Feel temperature of Liquid Line
at Condensing Unit
Does the Condenser Fan Motor
run below cut-out
setpoint in harvest?
Backseat Liquid Line Shut
Off Valve or Replace
Look for Restriction,
Correct Line Set Size,
& Proper Insulation
Refer to Fan Cycling
Control Diagnostics
Note: Some CVD675
Condensing Units may not
have a Fan Cycle Control
Cold
Cold
Cold
Feels Hot
Feels Hot
YES
NO
