Manitowoc QuietQube SD0672C

Part Number 80-1505-3 6/11 71
CVD
®
CONDENSING UNITS
CVD675/CVD685/CVD875/CVD885/CVD1075/CVD1085/
CVD1185/CVD1285/CVD1485
CVD1486
ACCESS
VALVE
CONDENSER
FAN MOTOR
HEAD PRESSURE
CONTROL VALVE
AIR
CONDENSER
COMPRESSOR
SUCTION
ACCUMULATOR
LIQUID LINE AND
SUCTION LINE
CONNECTION
POINTS
ELECTRICAL
COMPARTMENT
CHECK VALVE
ACCESS VALVE
LPCO
HEAD PRESSURE
CONTROL VALVE
ELECTRICAL
COMPARTMENT
COMPRESSOR
SUCTION
ACCUMULATOR
WATER
REGULATING
VALVE
LIQUID LINE
AND SUCTION LINE
CONNECTION
POINTS
WATER
COOLED
CONDENSER
