Part Number 80-1505-3 6/11 35
6. Secure the ice machine to the adaptor with two
(2) #8-32 screws supplied with the kit.
7. Set the bin cover on the adapter, move backwards
until the cover hits the stop, and lower the plastic
cover insuring that the latch locks.
8. To remove the bin cover, twist the knob, lift up,
and pull forward.
