PREVENTATIVE MAINTENANCE CD5515-2/YB5515-2 SERVICE MANUAL
5-16 Published 1-20-2017, Control# 483-02
have protection. Recheck to see if the sealing surface in
the housing is clean, or if the element is the right model
number. It may be too short for the housing.
4. Install the air cleaner housing cover.
5. Reset the air cleaner restriction indicator by pushing in
the reset button (Figure 5-33).
6. If a cleaned air cleaner element was installed, start the
engine and run at high idle. If the air cleaner restriction
indicator’s colored piston pops out and is visible again,
shut down the engine and replace the air cleaner
element with a new element.
Check Tire Pressure
Check the air pressure in the crane’s four tires. Correct
pressure is 9.31 bar (135 psi).
Also, check for broken studs, rim damage, loose nuts, cracks
and other tire damage.
