GROVE Published 1-20-2017, Control# 483-02 1-3
CD5515-2/YB5515-2 SERVICE MANUAL INTRODUCTION
GENERAL SPECIFICATIONS
Engine
Make and model................................................................................................Cummins QSB3.3L -4 Cyl. Diesel Tier 4i
Type of Aspiration .............................................................................................Turbocharged
Horsepower.......................................................................................................100 hp @ 2600 rpm
Low idle speed ..................................................................................................900 rpm
Intermediate Speed Control (ISC) Idle Speed ..................................................1200 rpm - Coolant Temperature is less than
..........................................................................................................................71° C (160° F)
Maximum engine speed....................................................................................2600 rpm
Tires
Size...................................................................................................................12.00R20
Type ..................................................................................................................Radial
Air pressure.......................................................................................................896 kPa (135 psi)
Wheel nut torque...............................................................................................680 Nm (500 lb-ft)
Electrical System
Rating................................................................................................................12 VDC negative ground
Number and type of batteries:
Standard Battery ...............................................................................................One-maintenance free
Battery (Two with cold weather start) ............................................................................. 150 amp/hr each
Battery rating.....................................................................................................150 amp/hr
Alternator ..........................................................................................................120 amps
FUEL TANK
Capacity .....................................................................................................151 L (40 gal)
HYDRAULIC SYSTEM
Primary Pump.............................................................................................Piston, 60 cc - CCW
Swing Motor ...............................................................................................Single section, gerotor-type
Hoist Motor.................................................................................................Gear
Hydraulic Filters..........................................................................................One 3-micron filter in line from valves One 30-
mesh suction filter inside hydraulic tank
Hydraulic Cylinders ....................................................................................Double-acting cylinders for lift, telescope,
steering and outriggers
Hydraulic Tank............................................................................................123 L (32 gal.) capacity, steel construction
with internal baffles
Boom
Reach (from center line of rotation)
3 Section Boom.................................................................................................12.50 m (41’ 0”)
4 Section Boom.................................................................................................15.24 m (50’)
Boom Extension - Fixed (optional) ....................................................................4.6 m (15 ft)
Reference Only
