Manitowoc Shuttlelift CD5515-2 Service And Maintenance Manual

INTRODUCTION CD5515-2/YB5515-2 SERVICE MANUAL
1-4 Published 1-20-2017, Control# 483-02
Boom Elevation.................................................................................................0° to 69°
MAST ROTATION - 360°
Mast Bearing (Diameter)............................................................................860.6 mm (33.884 in)
Swing Drive Mechanism.............................................................................Hydraulic motor driven gearbox
Swing Speed ..............................................................................................2.1 rpm
Wire Rope
Wire Rope (Main Hoist):
Domestic
Size........................................................................................................14.3 mm (9/16”) 6 x 19 EIPS-IWRC
Length...................................................................................................97.5 m (320 ft)
CE
Diameter ................................................................................................14 mm
Type .......................................................................................................8 x 25 EIPS-IWRC
Length....................................................................................................97.5 (320 ft)
Wire Rope (Optional Below Deck Winch):
Diameter ................................................................................................11.1 mm (7/16 in)
Length....................................................................................................35.1 m (115 ft)
Hydraulic System
Filters................................................................................................................10 micron return line filter
..........................................................................................................................30 mesh suction filter in tank
Weight
Crane Gross Vehicle Weight.............................................................................13,488 kg (29,735 lb)
Travel Speeds
Two-Wheel Steer
1st gear .................................................................................................6.4 km/hr (4 mph)
2nd gear................................................................................................11.3 km/hr (7 mph)
3rd gear.................................................................................................21 km/hr (13 mph)
4th gear.................................................................................................34 km/hr (21 mph)
Crane Gross Vehicle Weight.............................................................................13,488 kg (29,735 lb)
FRONT AXLE DRIVE
Type.......................................................................................................International Transmissions Limited
Model.....................................................................................................SD80 - Center Drive Head
REAR AXLE DRIVE
Type.......................................................................................................International Transmissions Limited
Model.....................................................................................................SD80 - Offset Drive Head
REAR AXLE NON-DRIVE
Reference Only

Manitowoc Shuttlelift CD5515-2 Specifications

General

Brand	Manitowoc
Model	Shuttlelift CD5515-2
Category	Construction Equipment
Language	English
