CD5515-2/YB5515-2 SERVICE MANUAL PREVENTATIVE MAINTENANCE
7
4
3
6
10
6
14
12
12
13
7650-65
FIGURE 5-54
8
6
3
Item Description
1 Hoist Tension Spring
2 Hoist Hose Connections
3 Pivot Shaft
4 Wire Rope
5 Hose Connections inside turntable
6
All Hardware, Clips, Pins, Hose Connections
not painted O/R Pins, Clips
7 Boom Nose Pins, Clips
8 Headache Ball/Hook Block
9 Turntable Bearing Fasteners
10 O/R Pins, Clips
11 Hook block Tiedown Cable
12 O/R Hose Connections
13 Entire underside of unit
14 Powertrain Hardware inside compartment
15 Boom Extension Pins, Clips - Option
16 Boom Extension Hanger Hardware - Option
