Manitowoc Shuttlelift CD5515-2 - Page 275

STRUCTURALS CD5515-2/YB5515-2 SERVICE MANUAL
11-22 Published 1-20-2017, Control# 483-02
Item Quantity Description
1 1 Plate, Side
2 20 Capscrew
3 1 Snap Ring
4 1 Gear Set
5 1 Drum Housing
6 2 Race, Bearing
8 1 Gear, Input Sun
9 12 Capscrew
10 1 Brake Piston
11 4 Screw
12 1 Base Plate
13 1 Brake Driver
14 2 Race
15 2 Snap Ring
16 1 Gear, Sun Output
17 2 Bushing
18 7 Friction Disc
19 8 Plate, Stator
20 1 Cover, Brake
21 1 Brake Housing
24 12 Brake Spring
26 1 Carrier, Bearing
28 2 Bearing
30 2 Breather
31 1 Sender, DRI/LLI
32 1 Shaft, Output
33 1 Plug, O-ring
34 1 Clutch
35 3 Fitting, 90 deg
36 1 Input Gear Set - 201 thru 207
38 1 Driver, Input
39 1 Bushing
40 2 Plug
41 1 Plug, Flush
42 1 Counterbalance Block
43 2 Support Rod
44 1 Motor Assy
45 4 Fitting, Adapter
49 1 Fitting, Tee
50 1 Plate, Side
52 4 Lockwasher, 1/2 ID
55 4 Capscrew
58 4 Counterbalance Valve
61 4 NCC Label
62 6 Capscrew
63 2 Screw, Buttonhead
64 1 Cord Set
65 1 Fitting, Tee
66 1 Fitting, Straight Adapter
69 1 Fitting, Reducer
70 1 Hose Assy
72 1 Fitting, Tee Adapter
73 1 Manifold Block
74 1 Valve, Cart. Solenoid
75 1 Hose Assy
77 3 Hose Assy
80 1 O-ring
81 1 Cord Set Rotation
82 1 Shaft DRI
101 1 Housing, Carrier
102 3 Gear, Planet
103 3 Pin
104 3 Retainer
105 1 Plate
106 6 Bearing
107 3 Spacer
108 6 Race, Bearing
201 1 Housing, Carrier
202 3 Gear, Planet
203 3 Pin
204 3 Retainer
205 1 Plate
206 3 Bearing
207 6 Race, Bearing
301 2 O-ring
302 1 O-ring
303 1 O-ring
304 1 O-ring
305 1 O-ring
306 2 Seal, Oil
307 1 Seal, Oil
308 1 O-ring
309 1 Ring, Back-up
310 1 Ring, Back-up
315 1 Kit, Seal
