ELECTRIC SYSTEM CD5515-2/YB5515-2 SERVICE MANUAL
3-12 Published 1-20-2017, Control# 483-02
Item Description Sheet 1
1 Right Front OMS
2 Right Front Turn Indicator
3 Right Front Headlight
4 Steer Solenoids
5 Outrigger Return
6 Outrigger Extend
7 Left Front Outrigger Beam
8 Left Front Jack
9 Right Front Jack
10 Right Front Outrigger Beam
11 Winch
12 Left Front OMS
13 Left Front Headlight
14 Left Front Turn Indicator
15 Ground Splice
16 Transmission Cooler Temperature Switch
17 Horn
18 Transmission Temperature Switch
19 Front Steering Proximity Switch
20 Main Control Valve
21 Hoist Down
22 Ground Splice
23 Outrigger Alarm Option
24 Brake Light Pressure Switch
25 Transmission Gear Shifter
26 Transmission Module
27 Park Brake
28 Brake Low Pressure Switch
29 Ground Splice
Reference Only
To Next Page
