ELECTRIC SYSTEM CD5515-2/YB5515-2 SERVICE MANUAL
3-14 Published 1-20-2017, Control# 483-02
Item Description Sheet 2
30 To Dash Harness
31 To Dash Harness
32 Ground Splice
33 360° Swing Lock
34 360° Swing Lock
35 To Cab
36 To Cab
37 Frame Grounds
38 To Dash Harness
39 To Dash Harness
40 To Dash Harness
41 PC1
42 Slew Proximity
43 Swivel
44 Ground Splice
45 Hydraulic Oil Temperature
46 Unloader Valve
47 2WD/4WD Solenoid
48 Fuel Level Sending Unit
49 Ground Splice
50 To Engine
51 Rear Steer Proximity Switch
