ELECTRIC SYSTEM CD5515-2/YB5515-2 SERVICE MANUAL
3-16 Published 1-20-2017, Control# 483-02
Item Description Sheet 3
52 Fuse/Relay Box
53 Transmission Temperature Switch, Tier 3
54 Module Connector
55 360° Swing Lock Option
56 Relays
57 Power Post (B)
58 Power Post (A)
59 Right Rear Turn Signal
60 Right Rear Work Light
61 Right Rear Stop/Tail Light
62 Right Rear OMS
63 Left Rear Turn Signal
64 Left Rear Work Light
65 Left Rear OMS
66 Left Rear Stop/Tail Light
67 A/C Binary Switch
68 Left Rear Outrigger Beam
69 Left Rear Outrigger Jack
70 Right Rear Outrigger Jack
71 Right Rear Outrigger Beam
72 Backup Alarm
Reference Only
