ELECTRIC SYSTEM CD5515-2/YB5515-2 SERVICE MANUAL
3-18 Published 1-20-2017, Control# 483-02
Item Description
1 Skylight Wiper
2 Carrier P6
3 Carrier P1
4 Carrier P2
5 Carrier P3
6 Carrier P5
7 Steering Return to Center
846 Splice
9 Ignition Switch
10 Outrigger Left Front
11 Outrigger Right Rear
12 Outrigger Right Front
13 Outrigger Left Rear
14 Ground Splice 2
15 Ground Splice 1
16 Ground Splice 3
17 Thumb Thumper
18 Park Brake
19 Crane Power
20 Hazard Switch
21 Locked Indicator
22 RCL Override
23 LSI Display
24 Winch Switch
25 71 Splice
26 Swing Lock Switch
27 Diagnostic
28 J1939 Blue
29 J1939 Orange
30 Fuse Box #2
31 Shift/Turn Right B
32 Shift/Turn Left A
33 Flasher
34 Transmission Pressure Alarm
35 Steering Select Switch
36 2WD/4WD Select Switch
37 Work/Headlights
38 Screen Toggle Switch
39 Defroster Fan
40 Cluster Gauge
41 RCL Display
42 Defroster Switch
43 Heater Switch
44 Hoist Speed Switch
45 Outrigger Extend/Retract Switch
46 Emergency Stop Switch
47 Windshield Wiper
48 221 Splice
49 Windshield Washer
50 Fuse Box #1
Reference Only
