4. AUDIO PWB
(1) Remove the screws.
(2) Remove the screws. Disconnect the connector wires.
Proceeding :
AUDIO PWB
→
TOP COVER
Direction of photograph: A
AUDIO PWB
CN42
CN81
CN43
