Marantz CD5004 Service Manual

7
DISASSEMBLY
• Disassemble in order of the arrow of the gure of following ow.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling" it.
• If wire bundles are untied or moved to perform adjustment or parts replacement etc., be sure to rearrange them neatly
as they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
FRONT PWB
(Ref. No. of EXPLODED VIEW : 14)
HEADPHONE PWB
(Ref. No. of EXPLODED VIEW : 16)
TACT SW PWB
(Ref. No. of EXPLODED VIEW : 15)
POWER PWB
Refer to "DISASSEMBLY
3. POWER PWB"
and "EXPLODED VIEW"
POWER PWB
(Ref. No. of EXPLODED VIEW : 31)
MECHA ASSY
Refer to "DISASSEMBLY
5. MECHA ASSY"
and "EXPLODED VIEW"
CABINET TOP
MAIN PWB
Refer to "DISASSEMBLY
2. MAIN PWB"
and "EXPLODED VIEW"
MAIN PWB
(Ref. No. of EXPLODED VIEW : 30)
AUDIO PWB
Refer to "DISASSEMBLY
4. AUDIO PWB"
and "EXPLODED VIEW"
AUDIO PWB
(Ref. No. of EXPLODED VIEW : 29)

Marantz CD5004 Specifications

General

DAC	CS4392
Frequency Response	2 Hz - 20 kHz
Signal to Noise Ratio	110 dB
Dynamic Range	100 dB
Total Harmonic Distortion	0.002%
Channel Separation	100 dB
Digital Output	Coaxial, Optical
Headphone Output	Yes
Power Consumption	14 W
Disc Formats	CD, CD-R/RW
Audio Outputs	Analog (RCA)
Dimensions	440 x 340 x 105 mm
Output Level	2.0 Vrms
