Marantz CD5004 - Waveforms

31
2. WAVEFORMS
T
1. DISC PLAY RF WAVEFORM（EYE-PATTERN） 2. DISC DETECTION
1.1 CD（TCD-784）Play 2.1 CD（TCD-784）DISC DETECTION
1.2 CD-R（TCD-R000RM）Play
2.2 CD-R（TCD-R000RM）DISC DETEC
1.3 CD-RW（TCD-W000RM）Play
2.3 CD-RW（TCD-W000RM）DISC DETECTION
RF
FE

Focus

TE
Tracking
SLID
SPIN
1V
200mV
2V
500Mv
2V
1V
2V

1V
200mV
2V
500Mv
2V
1V
2V

1V
200mV
2V
500Mv
2V
1V
2V
RF
FE
Focus
TE
Tracking
SLID
SPIN
RF
FE
Focus
TE
Tracking
SLID
SPIN
