Marantz CD6005 - Mecha Assembly Disassembly

5. MECHA ASSY
Proceeding : TOP COVER
→
FRONT PANEL ASSY
→
MECHA ASSY
(1) Remove the screws.
(2) Laser short-circuit in Pick-up of CD MECHANISM ASS'Y, then disconnect the connector wires and FFC cable.
Be sure to wear a grounding band.
Disconnect the connector wire.
Soldering place
FFCCWC100 CWC101
16
