Marantz CD6005 - Page 58

45
DCD-710AE
Pin
No.
Symbol I/O Description
Default Remarks
21
FSMoNiT
O
3AI/F
Focus Error signal / Sub beam add signal
output pin(monitor pin/GND)
O
22
RFZi
I
3AI/F
㪩㪝㩷㫉㫀㫇㫇㫃㪼㩷㫑㪼㫉㫆㪄㪺㫉㫆㫊㫊㩷㫊㫀㪾㫅㪸㫃㩷㪠㫅㫇㫌㫋㩷㫇㫀㫅 I
23
RFRP
O
3AI/F
㪩㪝㩷㫉㫀㫇㫇㫃㪼㩷㫊㫀㪾㫅㪸㫃㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅㪅 O
24
TEi
O
3AI/F
㪫㫉㪸㪺㫂㫀㫅㪾㩷㪼㫉㫉㫆㫉㩷㫊㫀㪾㫅㪸㫃㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅㪅 O
Bulit-in serises R=500:㪅
㩷
Connect to VRo by
capacitor.
25
AVDD3 -
Power supply pin for 3.3 V CD analog circuits.
-
26
FOo
O
3AI/F
㪝㫆㪺㫌㫊㩷㫊㪼㫉㫍㫆㩷㪼㫈㫌㪸㫃㫀㫑㪼㫉㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅㪅 O
Bulit-in serises R=3.3 k:
27
TRo
O
3AI/F
㪫㫉㪸㪺㫂㫀㫅㪾㩷㫊㪼㫉㫍㫆㩷㪼㫈㫌㪸㫃㫀㫑㪼㫉㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅㪅 O
Bulit-in output R=3.3 k:
28
VSS-3 -
Grounding pin for 1.5V Decoder-DSP
CD circuit
-
29
FMo
O
3AI/F
㪝㪼㪼㪻㩷㫊㪼㫉㫍㫆㩷㪼㫈㫌㪸㫃㫀㫑㪼㫉㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅㪅 O
Bulit-in output R=3.3 k:
30
FMoS
O
3AI/F
Feed servo 㪼㫈㫌㪸㫃㫀㫑㪼㫉㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅㪅
䋨Stepper motor application䋩
O
Bulit-in output R=3.3 k:
31
DMo
O
3AI/F
㪛㫀㫊㪺㩷㫊㪼㫉㫍㫆㩷㪼㫈㫌㪸㫃㫀㫑㪼㫉㩷㫆㫌㫋㫇㫌㫋㩷㫇㫀㫅 O
Bulit-in output R=3.3 k:
32
VDD1-3
I/O
3I/F
Power supply pin for 1.5V Decoder-DSP
/CD circuit
-
33
Pio8
I/O
3I/F
Port 8䋨General Input/Output Port 䋩 I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
34
Pio9
I/O
3I/F
Port 9䋨General Input/Output Port 䋩 I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
35
Pio10
I/O
3I/F
Port 10䋨General Input/Output Port 䋩 I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
36
Pio11
I/O
3I/F
Port 11䋨General Input/Output Port 䋩 I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
37
Pio12/
CDMoN0/
FGiN
I/O
3I/F
Port 12䋨General Input/Output Port 䋩
/ CD Monitor 0 / FG signal input
I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
38
Pio13/
CDMoN1
I/O
3I/F
Port 13䋨General Input/Output Port 䋩
/ CD Monitor1
I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
39
Pio14/
CDMoN2
I/O
3I/F
Port 14䋨General Input/Output Port 䋩
/ CD Monitor 2
I
CMOS Port
Schmitt input
Refer to [1.2 Pin Assinment Table]
40
CDMoN3
O
3I/F
CD Monitor3 (Default output : SBSY) O
CMOS Port
Refer to [1.2 Pin Assinment Table]
58
