Explanatory Photos for“ DISASSEMBLY”
• The angles from which the photos are taken are shown by “Photo angle: A, B, C, D“ .
• See the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the set.
• The photograph is HD-DAC1N1SG.
The viewpoint of each photograph
(Shooting direction) Top view
Front side
Shooting
direction: D
Shooting
direction: C
↑Shooting direction: A↑
↓Shooting direction: B↓
