Marantz HD-DAC1 - 1. SIDE PANEL DISASSEMBLY

1. SIDE PANEL
Proceeding : SIDE PANEL
(1) Remove the screws.
(2) Remove the screws.
(2) Slide to the front side of the side panel, and remove to lift from the bottom.
View from the rear
View from the bottom
TOP
bottom
View from the side
14
