Marantz HD-DAC1 - IC Pin Assignments (Part 2)

60 PE9 DIR1_CIDO I - I IC42(DIR IC:PCM9211PTR)_23PIN
61 VSS_7 - - - FIXED TO THE GND
62 VDD_7 - - - 3.3V
63 PE10 DIR1_CLK O - O/L IC42(DIR IC:PCM9211PTR)_25PIN
64 PE11 DIR1_CE O - O/L IC42(DIR IC:PCM9211PTR)_26PIN
65 PE12 DIR1CODI O - O/L IC42(DIR IC:PCM9211PTR)_24PIN
66 PE13 ACP_RST O - O/L IC14(FONT IC:MFI337S3959)_7PIN
67 PE14 ACP_SDA O - O/L IC14(FONT IC:MFI337S3959)_2PIN, IC31, G18
IC22, 9pin
68 PE15 ACP_SCL O - O/L IC14(FONT IC:MFI337S3959)_6PIN, IC31, G16
IC22, 10pin
69 PB10 NC I/O - O/L NC
70 PB11 NC O - O/L NC
71 VSS_1 - - - FIXED TO THE GND
72 VDD_1 - - - 3.3V
73 PB12 USBB_RST O - O/L IC31(USBB DRIVER IC:TMS320C6748BZWT)_
K14
74 PB13 USBB_DETECT I - I IC31(USBB DRIVER IC:TMS320C6748BZWT)_
N19
75 PB14 USBB_INT I - I IC31(USBB DRIVER IC:TMS320C6748BZWT)_
W14PIN
76 PB15 44/48 O - O/L IC26(SW IC:TC74LCX157)_1PIN
77 PD8 DAC_CK_IN O - O/L IC21(DSP IC: M240T100C5N)_52PIN
78 PD9 DAC_DATA_IN O - O/L IC21(DSP IC: M240T100C5N)_54PIN
79 PD10 DAC_CS_IN O - O/L IC21(DSP IC: M240T100C5N)_53PIN
80 PD11 TRST O - O/L TRST
81 PD12 ADET I - I ADET
82 PD13 NC O - O/L NC
83 VSS_8 - - - FIXED TO THE GND
84 VDD_8 - - - 3.3V
85 PD14 AE1_WP O - O/L IC43(SERIAL FRESH IC: MX25L4006EM2I)_3PIN
86 PD15 AE1_CTS I - I IC41(USB IC:UPD63530AGA)_4PIN
87 PG2 AE1_SIMO O - O/L IC41(USB IC:UPD63530AGA)_2PIN
88 PG3 AE1_SOMI I - I IC41(USB IC:UPD63530AGA)_3PIN
89 PG4 AE1_MC_SCK O - O/L IC41(USB IC:UPD63530AGA)_1PIN
90 PG5 P_CONT O - O/L POWER CTL
91 PG6 NC O - O/L NC
92 PG7 AE1_RTS O - O/L IC41(USB IC:UPD63530AGA)_5PIN
93 PG8 AE1_RST O - O/L IC41(USB IC:UPD63530AGA)_16PIN
94 VSS_9 - - - FIXED TO THE GND
95 VDD_9 - - - 3.3V
96 PC6 NC O - O/L NC
97 PC7 NC O - O/L NC
98 PC8 NC O - O/L NC
99 PC9 NC O - O/L NC
100 PA8 NC O - O/L NC
101 PA9 UPDATE_TX O - O/L UPDATE TX
102 PA10 UPDATE_RX I - I UPDATE RX
103 PA11 NC O - O/L NC
104 PA12 NC O - O/L NC
105 PA13 DEBUG I - - JTMS / SWDIO
106 PCAP_2 - - - Not Connected
107 VSS_2 - - - FIXED TO THE GND
108 VDD_2 - - - 3.3V
109 PA14 DEBUG I - - JTCK / SWCLK
110 PA15 DEBUG I - - JTDI
111 PC10 NC O - O/L NC
112 PC11 NC O - O/L NC
113 PC12 NC O - O/L NC
114 PD0 AMUTE O - O/L AMUTE
115 PD1 NC O - O/L NC
116 PD2 NC O - O/L NC
