Marantz HD-DAC1 - AUDIO;POWER PCB ASSY Component List; Audio;Power PCB Semiconductors

AUDIOandPOWER
AUDIOandPOWER PCB ASS'
Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D601-608 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 8
D647 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D701-708 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 8
D901-906 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 6
D907,908 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 2
D909 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25 1
D911 943202500750M DIODE , ZENER(8.2V/0.5W, SOD-123) CVDMM1Z8V2H 1
D912,913 943203500550S DIODE , BRIDGE(600V/6A) CVDD5SB60 2 *
D914-917 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 4
D918 943202001360S DIODE , ZENER ,1/2W, 20V CVDZJ20BT 1
D919 963202010440S DIODE , ZENER ,1/2W, 22V CVDZJ22BT 1
D920 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 1
D921 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D923-927 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 5
D929,930 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 2
D951,952 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 2
D953-956 00MHD20055100 EOL item DIODE , SCHOTTKY (100V/1A) CVD11EQS10GT 4
D957 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D958 943202500890D DIODE , ZENER(13V/0.5W, SOD-123) CVDMM1Z13H 1
D959,960 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 2
D961 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D962 943202500830S DIODE , ZENER(CHIP,6.2V) HVDUDZS6.2BSR 1
D965 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D966 943202500830S DIODE , ZENER(CHIP,6.2V) HVDUDZS6.2BSR 1
D967-969 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 3
D971,972 nsp DIODE , ULTRA FAST RECTIFIER CVDUS1M 2
IC61 90M-HC109330R AUDIO DAC (TSSOP-28 PACKAGE) HVICS4398CZ 1
IC63,64 943233102000S I.C , 2-CHANNEL MUX(VSSOP-16P) CVITC74LCX157FK 2
IC91 00D2631242905 I.C , VOLTAGE REGULATOR(3.3V, SOP-23-5) CVINJM2831F33 1
IC92,93 943219500150M I.C, REGULATOR 5PIN,5V, 1.5A CVIBA00JC5WT 2
IC94,95 90M-HC300740R REGULATOR(3.3V OUTPUT LOWDROP) HVIKIA278R33PI 2
IC96 00D2631162014 REGULATOR (5V OUTPUT LOW DROP) HVIKIA78R05PI 1
IC97 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
! IC98 00MHC3890599F I.C,REGULATOR
(
+5V,T0220IS
)
HVIKIA7805AP
I
1
IC99 943219500160M I.C, REGULATOR(1.0A, 3.3V, SOT-223) CVILM1117S33 1
Q601 943222500200D F.E.T , 2SK2145 (N-CH, 2-3L1C, LOW NOISE, TOSHIBA) CVT2SK2145 1
Q602 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q603 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q604 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q605 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q606 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q607 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q608 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q609 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q610,611 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 2
Q612 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q613,614 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
Q615 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q616 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q617,618 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 2
Q619 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q620 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1
Q621 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q623,624 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 2
Q625 00MHT900291B0 T.R , BIAS HVTKTD600KGR 1
Q626 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q627 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q628 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1
Q632 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q633 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q634 00D2730471907 T.R HVTKTC3206YAT 1
Q635 00D2710314903 T.R HVTKTA1024YT 1
Q636 90M-HT300940R T.R , DRIVER HVT2SC4883A 1
Q637 90M-HT100690R T.R , DRIVER HVT2SA1859A 1
Q638 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q639 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1
Q643 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q644 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1
Q645 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q646 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1
Q647-650 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 4
Q653 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1
Q681 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1
Q701 943222500200D F.E.T , 2SK2145 (N-CH, 2-3L1C, LOW NOISE, TOSHIBA) CVT2SK2145 1
Q702 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q703 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q704 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q705 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q706 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q707 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q708 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q709 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q710,711 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 2
Q712 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q713,714 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
Q715 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q716 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q717,718 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 2
Q719 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q720 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1
Q721 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q723,724 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 2
Q725 00MHT900291B0 T.R , BIAS HVTKTD600KGR 1
Q726 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q727 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
Q728 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1
Q732 00MHX300012AY T.R, 2SC4116, NPN, SC-70, TOSHIBA CVT2SC4116 1
Q733 212050002507S T.R, 2SA1586, PNP, SC-70, TOSHIBA CVT2SA1586 1
