13
(4) Disconnecttheconnectorboard.
(5) Removethescrews.
(6) Disconnecttheconnectorwires.
PCB HDMI
Board to board
Board to board
Board to board
PCB AUDIO_VIDEO
PCB AUDIO VIDEO
PCB FRONT CNT
PCB SIDE CNT
CP401 CP13A
CP10
CN3
