Marantz NR1601 - PARTS LIST OF EXPLODED VIEW; Note: The symbols in the column Remarks indicate the following destinations.; Ref.No. Part No. Part Name

PARTS LIST OF EXPLODED VIEW
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model
B : Black model SG : Silver gold model
Ref.No. Part No. Part Name Remarks Q'ty New
25 nsp PCB 7CH_AMP ASSY N1B 7025HK0928040 *
25 nsp PCB 7CH_AMP ASSY N1SG 7025HK0928030 *
25 nsp PCB 7CH_AMP ASSY U1B 7025HK0928010 *
42A nsp PCB SPK ASSY N1B 7025HK0928041
42A nsp PCB SPK ASSY N1SG 7025HK0928031
42A nsp PCB SPK ASSY U1B 7025HK0928011
41 - PCB SMPS
42 - PCB SPK
44A nsp PCB REG_CNT ASSY N1B 7025HK0928042 *
44A nsp PCB REG_CNT ASSY N1SG 7025HK0928032 *
44A nsp PCB REG_CNT ASSY U1B 7025HK0928012 *
20 - PCB GUIDE_L
29 - PCB GUIDE_H/S
30 - PCB GUIDE_R
43 - PCB REG_CNT
44 - PCB REG
45 - PCB FRONT_CNT
47 - PCB SIDE_CNT
50 - PCB RC-5/M-X
26A nsp PCB FRONT ASSY N1B 7025HK0928043 *
26A nsp PCB FRONT ASSY N1SG 7025HK0928033 *
26A nsp PCB FRONT ASSY U1B 7025HK0928013 *
11 - PCB H/P
16 - PCB USB
26 - PCB FRONT
48 nsp PCB AUDIO_VIDEO ASSY N1B 7025HK0928044
48 nsp PCB AUDIO_VIDEO ASSY N1SG 7025HK0928034
48 nsp PCB AUDIO_VIDEO ASSY U1B 7025HK0928014
49 8U6331006400M PCB HDMI ASSY N1B 7025HK0928045
49 - PCB HDMI ASSY N1SG 7025HK0928035
49 - PCB HDMI ASSY U1B 7025HK0928016
Ref.No. Part No. Part Name Remarks Q'ty New
1 963412005880S VOLUME KNOB ASSY(KD) U1B,N1B 5088212028000SZ 2
1 963412005890S VOLUME KNOB ASSY(KD) N1SG 5088212028010SZ 2
2 - NUT - 2
3 963419006180M RING KNOB U1B,N1B 5127210901000S 2
3 963419006190M RING KNOB N1SG 5127210901100S 2
4 963402011970M PANEL FRONT(L) U1B,N1B 3067214571020S 1 *
4 963402011980M PANEL FRONT(L) N1SG 3067214571210S 1 *
5 963421006200M BADGE(MARANTZ) SILVER/GRAY 5630210678000S 1
6 963416011990M WINDOW DISPLAY(ACRYL RED WINE) 5077212733010S 1 *
7 963402011640M FRONT PANEL U1B,N1B 3067214468100S 1 *
7 963402011650M FRONT PANEL N1SG 3067214468120S 1 *
8 963402006020M FRONT PANEL(R) U1B,N1B 3067214561000S 1
8 963402006030M FRONT PANEL(R) N1SG 3067214561200S 1
9 963411006110M BUTTON POWER U1B,N1B 5090213961000S 1
9 963411012000M BUTTON POWER N1SG 5097213961100S 1 *
10 963481006080M LENS STANDBY 3710210873000S 1
12 963481006070M LENS HDMI 3710210843000S 2
13 963411006100M BUTTON 4KEY U1B,N1B 5090213861000S 2
13 963411006120M BUTTON 4KEY N1SG 5097213861100S 2
14 963411006130M BUTTON ENTER-2 U1B,N1B 5097213871000S 1
14 963411006140M BUTTON ENTER-2 N1SG 5097213871100S 1
15
nsp FRAME PANEL U1B,N1B 3417210211000S 1
15 nsp FRAME PANEL N1SG 3417210211100S 1
17 963411006150M BUTTON ENTER-1 U1B,N1B 5097213911000S 1
17 963411006160M BUTTON ENTER-1 N1SG 5097213911100S 1
18 nsp FRONT BRACKET 4010214156000S 1
19 nsp HEAT SINK MAIN 2120211838000S 1 *
★
21 00D9960018706 TR 2SB1560-Y
Q410,Q422,Q434,Q446,
Q458,Q470,Q482
J5011560Y0000S 1
★
22 963219003340S TR KTC3964/TO126S-BULK
Q409,Q421,Q433,Q445,
Q457,Q469,Q481
J502396400010S 1
★
23 00D9960018706 TR 2SD2390-Y
Q404,Q416,Q428,Q440,
Q452,Q464,Q476
J5032390Y0000S 1
24 nsp BRACKET HEAT SINK 4010056906010S 5
27 nsp ACETATE CLOTH TAPE D-XW33(J) 1220210129300S 1
28 nsp ACETATE CLOTH TAPE DMS3 1220210059020S 2
31 nsp CABINET SHEET 1210210235000S 1
32 nsp CHASSIS MAIN 3200213586000S 1 *
33 963403012010M TOP COVER U1B,N1B 3007211786000S 1 *
33 963403012020M TOP COVER N1SG 3007211786010S 1 *
34 00M46BW057210 FOOT FRONT 4007210321000S 4
35 nsp BRACKET SIDE 4010210686000S 1
36 nsp SUPPORTER P.C. 4070210192000S 1
37 nsp SUPPORTER PCB 4070001601010S 1
z
38 963101011620M POWER TRANS MAIN N1B,N1SG 8200858630390S 1 *
z
38 963101011610M POWER TRANS MAIN U1B
8200858630370S 1 *
39 nsp CHASSIS BACK U1B 3207213576100S 1 *
39 nsp CHASSIS BACK N1B,N1SG 3207213576020S 1 *
40 nsp BRACKET SMPS 4010214886000S 1
46 nsp SPACER CARD 4300210062000S 1
51 nsp BUSHING TERMINAL N1B,N1SG 2410040353010S 18
★
60 nsp TAPE INLET 1220210759000S 1
★
61 963606010490S CABLE,FLAT CARD 1.0MM N711402912480S 1
d
d
d
91
NOTE :
Please change the destination-resistors when changing 1601N1B (8U6331006400M) to other destination.
Please refer to destination-resistors 85,86 page.
(SCHEMATIC DIAGRAMS : 21/24, 22/24)
U2905(21/24) C2907(21/24) R2906(21/24) R2908(21/24) R2909(21/24) R2938(21/24) R3119(22/24) R3122(22/24)
1601N1B
TC74VHC08FT 0.1/10 33 33 33 470K OPEN 10K
1601N1SG
TC74VHC08FT 0.1/10 33 33 33 470K OPEN 10K
1601U1B OPEN OPEN OPEN OPEN OPEN OPEN 10K OPEN
