1. FRONT PANEL ASSY
(1) Removethescrews.
(2) Cutthewireclampbands,thenremovethescrews.
CABINET TOP
FRONT PANEL ASSY
→
Proceeding :
View from bottom
Direction of
photograph: D
Direction of
photograph: C
cut
