Marantz NR1601 - Surround Modes and Parameters; Symbols in the table

28
SURROUND MODES AND PARAMETERS
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Confi g.”.
Surround mode
Channel output Surround Parameter
Front
L/R
Center
Surround
L/R
Surround Back
L/R
Front Height L/R Subwoofer
HT-EQ.
z3
DRC z4
D. Comp
z5
LFE
z6
DIRECT (2channel)
S D
z2
S S
DIRECT (Multi-channel)
S D D D
z1
D
z1
D S S S
STEREO
S D S S S
MULTI CH IN
S D D D D D S S
DOLBY PRO LOGIC gz S D D D D S S S
DOLBY PRO LOGIC gx S D D D D S S S
DOLBY PRO LOGIC g S D D D S S S
DTS NEO:6
S D D D D S S S
DOLBY DIGITAL
S D D D D D S S S
DOLBY DIGITAL Plus
S D D D D D S S S
DOLBY TrueHD
S D D D D D S S S
DTS SURROUND
S D D D D D S S S
DTS 96/24
S D D D D D S S S
DTS-HD
S D D D D D S S S
DTS Express
S D D D D D S S S
MULTI CH STEREO
S D D D D D S S
DOLBY VIRTUAL SPEAKR
S D
z2
S S
Neural
S D D D D S S S
Dolby Headphone
S S S S
z1 A signal for each channel contained in an input signal is output as audio. z2 Only when “Subwoofer Mode” is set to “LFE+Main”-, sound is output from the subwoofer. z3 For HD Audio whose sampling frequency of an input signal is more than 96kHz, this sound parameter cannot be set. z4 This item can be selected when a Dolby TrueHD signal is played. z5 This item can be selected when a Dolby Digital or DTS signal is played. z6 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.
