Speaker A/B connection
•The same signal is output from the SPEAKERS A and SPEAKERS B terminals.
•When only one set of speakers is to be connected, use either the SPEAKERS A or SPEAKERS B terminals.
w qw q
(R) (L)
w qw q
(R) (L)
SPEAKERS A SPEAKERS B
