Specifications
•RMS Power output
(20 Hz – 20 kHz simultaneous drive of both channels) : 70 W x 2 (8 Ω/ohms load)
100 W x 2 (4 Ω/ohms load)
•Total harmonic distortion
(20 Hz – 20 kHz simultaneous drive of both channels,
8 Ω/ohms load) : 0.02 %
•Output band width (8 Ω/ohms load, 0.06 %) : 5 Hz – 60 kHz
•Frequency response (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 100 kHz ±3.0 dB
•Dumping factor (8 Ω/ohms load, 40 Hz – 20 kHz) : 100
•Input sensitivity/Input impedance
PHONO (MM) :
CD, TUNER, NETWORK, AUX, RECORDER :
POWER AMP DIRECT IN :
2 mV / 47 kΩ/kohms
200 mV / 20 kΩ/kohms
1.6 V / 15 kΩ/kohms
•Output voltage/Output impedance
PRE OUT : 1.6 V / 600 Ω/ohms
•Maximum allowable PHONO input level (1 kHz)
MM : 100 mV
•RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
