Paths to be conrmed Display Settings What to conrm
8
Analog Amp Assign
(Amp Assign :
ZONE3)
g.A08
A08:ASSIGN-Z3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
ZONE3 Source : CBL/SAT(select a setting other than Source)
Amp assign : 9.1ch + ZONE3
Speaker for ZONE3 : Height3, FrontWide
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : On
・ Analog input ⇒ Speaker output (Height3, FrontWide (ZONE3), L/R)
・ Analog input ⇒ Pre OUT output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
9
Analog Amp Assign
(Amp Assign :
ZONE2/ZONE3-
MONO)
g.A09
A09:ASSIGN-Z2/3M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
ZONE2 Source : Source : CBL/SAT(select a setting other than Source)
ZONE3 Source : Source : CBL/SAT(select a setting other than Source)
Amp assign : 9.1ch + ZONE2/3-MONO
Speaker for ZONE2/3 : Height2
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : On
・ Analog input ⇒ Speaker output (Height2 (ZONE2 MONO L), Height2 (ZONE3 MONO) R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R MONO, ZONE3 L/R MONO)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
10
Amp Assign
(Amp Assign :
BiAMP)
g.A10a
g.A10b
A11:ASSIGN-BiAMP
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch + BiAMP
Speaker for Bi-Amp : S.Back
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (S.Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
11 Front Height
g.A11a
g.A11b
A14:FRONT HEIGHT
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 13.1ch
Floor Layout : 5ch&SB
Height Sp : 6ch
Dolby Sp : None
Height Layout : Top Front & Top Middle & Top Rear
Pre-out channel : Top Middle
Speaker Select = Floor & Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (Height1 L/R (Top Front), Height2 L/R (Top Rear))
・ Analog input ⇒ Pre OUT output
(Height1 L/R (Top Front), Height2 L/R (Top Rear), Height3 L/R (Top Middle))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
12 Front Wide
g.A12a
g.A12b
A15:FRONT WIDE
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 13.1ch
Floor Layout : 5ch&FW
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height
Rear Height
Pre-out channel : Rear Height
Speaker Select = Floor & Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・Analog input ⇒ Speaker output (Hgight3 L/R (Front Wide)
・Analog input ⇒ Pre OUT output (Hgight3 L/R (Front Wide)
・ Pre OUT output
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
