Paths to be conrmed Display Settings What to conrm
13 7.1ch g.A13
A19:7.1CH IN
Input Source : CBL/SAT
Input Mode : 7.1Ch In
Amp Assign : 13.1ch
Floor Layout : 5ch & SB
Height Sp. : None
Dolby Sp : None
Speaker Cong ALL Speaker=Small/SW=Yes(2ch)
・ 7.1ch In input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R)
・ Pre OUT output (Front L/R, Center, Surround L/R, S.Back L/R, Subwoofer1/2)
14
Front Amp-Front
Wide
g.A14a
g.A14b
A21:F-AMP WIDE
Input Source : CBL/SAT
Input Mode : Auto
SURROUND mode : Multi ch STEREO
Amp assign : 13.1ch
Floor Layout : 5ch&SB&FW
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
Pre-out Channel : Front
Speaker Select : Floor & Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (Height3/Front Wide L/R(Front Wide)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
15
ZONE2 Downmix
(Amp Assign :
ZONE2)
g.A15a
g.A15b
A22:Z2 Downmix
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
ZONE2 Source : Source
Amp assign : 9.1ch + ZONE2
Speaker for ZONE2 : Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : On
ZONE3 : Off
・ Analog input ⇒ Speaker output (Height2 (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source for ZONE2 can be switched to any source except CBL or SAT.)
(Do not change the input source for ZONE2 from "SOURCE".)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
16 5.1ch Full Bi-Amp
g.A16a
g.A16b
A27:5ch Bi-Amp
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 5.1ch Full Bi-amp
Floor Layout : 5ch
Height Sp : N/A
Dolby Sp : N/A
Height Layout : N/A
Speaker Select=N/A
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog 入力 ⇒ Speaker 出力 (S.Back L/R (Front Bi-Amp), Height1 L (Center Bi-Amp), Height2 L/R
(Surround Bi-Amp)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
17
Bi-Amp
(Amp Assign :
BiAMP-Surround
Back Amp)
g.A17a
g.A17b
A28:Bi-Amp + Z2
Input Source : CBL/SAT
Input Mode : Auto
Sound Mode : Stereo
Amp Assign : 7.1ch (Bi-Amp) + ZONE2
Speaker for Bi-Amp : Height3/Front Wide
Floor layout : 5ch & SB
Height Sp : None
Dolby Sp : None
Height Layout : N/A
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (Height3/Front Wide L/R (Front Bi-Amp))
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative
settings are used)
