Marantz SR 8015 - Page 74

ADSP-21573KBCZ4D10 (DIGITAL : U0102)
ADSP-21573KBCZ4D6 (DIGITAL : U0252)
Terminal Function
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
1517
14
13
12
11
10
9
8
7
6
5
4
3
2
1
16
19
18 20
T
U
V
W
Y
BOTTOM VIEW
Ball No. Pin Name
A01 GND
A02 PA_10
A03 PA_09
A04 PA_11
A05 PE_07
A06 MLB0_CLKN
A07 MLB0_CLKP
A08 MLB0_SIGN
A09 GND
A10 SYS_XTAL 0
A11 SYS_C LKIN0
A12 GND
A13 SYS_XTAL 1
A14 SYS_C LKIN1
A15 GND
A16 USB0_DP
A17 USB0_DM
A18 PF_03
A19 PF_05
A20 GND
B01 PC_12
B02 GND
B03 PA_13
B04 PA_15
B05 PB_01
B06 PB_04
B07 MLB0_DATN
B08 MLB0_DATP
B09 MLB0_SIGP
B10 JTG_TRST
B11 USB0_VBUS
B12 USB0_XTAL
B13 PB_10
B14 JTG_TDO
B15 JTG_TMS
B16 PF_00
B17 PF_01
B18 PF_06
B19 GND
B20 PF_07
C01 PC_11
C02 PC_13
C03 GND
C04 PA_12
C05 PA_14
C06 PB_03
C07 PB_02
C08 PE_10
C09 PB_06
C10 PB_05
C11 SYS_HWRST
C12 USB0_ID
C13 USB0_CLKIN
C14 PB_12
C15 PB_13
C16 JTG_TDI
C17 PE_14
C18 GND
C19 PF_08
C20 PF_11
D01 PC_06
D02 PC_08
D03 PE_04
D04 GND
D05 PE_08
D06 PE_11
D07 PE_09
D08 PB_08
D09 PB_07
D10 PB_09
D11 SYS_CLKOUT
D12 PB_11
D13 USB0_VBC
D14 PB_14
D15 PE_13
D16 PE_12
D17 GND
D18 PF_10
D19 DAI0_PIN01
D20 DAI0_PIN04
E01 PC_05
E02 PE_05
Ball No. Pin Name
E03 PE_03
E04 PE_02
E05 GND
E06 PB_00
E07 VDD_EXT
E08 VDD_EXT
E09 VDD_EXT
E10 VDD_EXT
E11 VDD_EXT
E12 VDD_EXT
E13 VDD_USB
E14 JTG_TCK
E15 PE_15
E16 GND
E17 VDD_EXT
E18 PF_04
E19 DAI0_PIN07
E20 DAI0_PIN03
F01 PC_02
F02 PC_03
F03 PC_04
F04 PE_06
F05 VDD_INT
F06 GND
F07 VDD_INT
F08 VDD_INT
F09 VDD_INT
F10 VDD_INT
F11 VDD_INT
F12 VDD_INT
F13 VDD_INT
F14 VDD_INT
F15 GND
F16 VDD_INT
F17 PF_02
F18 PF_09
F19 DAI0_PIN02
F20 DAI0_PIN06
G01 PC_00
G02 PC_14
G03 PC_01
Ball No. Pin Name
G04 VDD_EXT
G05 VDD_INT
G06 GND
G07 GND
G08 GND
G09 GND
G10 GND
G11 GND
G12 GND
G13 GND
G14 GND
G15 GND
G16 VDD_INT
G17 PB_15
G18 DAI0_PIN08
G19 DAI0_PIN10
G20 DAI0_PIN09
H01 PE_01
H02 PC_09
H03 PC_15
H04 VDD_EXT
H05 VDD_INT
H06 GND
H07 GND
H08 GND
H09 GND
H10 GND
H11 GND
H12 GND
H13 GND
H14 GND
H15 GND
H16 VDD_INT
H17 VDD_EXT
H18 DAI0_PIN05
H19 DAI0_PIN14
H20 DAI0_PIN11
J01 PE_00
J02 PC_07
J03 PC_10
J04 VDD_EXT
Ball No. Pin Name
J05 VDD_INT
J06 GND
J07 GND
J08 GND
J09 GND
J10 GND
J11 GND
J12 GND
J13 GND
J14 GND
J15 GND
J16 VDD_INT
J17 VDD_EXT
J18 DAI0_PIN12
J19 DAI0_PIN13
J20 DAI0_PIN16
K01 PD_14
K02 PD_13
K03 PD_15
K04 VDD_EXT
K05 VDD_INT
K06 GND
K07 GND
K08 GND
K09 GND
K10 GND
K11 GND
K12 GND
K13 GND
K14 GND
K15 GND
K16 VDD_INT
K17 VDD_EXT
K18 DAI0_PIN15
K19 DAI0_PIN19
K20 DAI0_PIN18
L01 PD_11
L02 PD_10
L03 PD_12
L04 VDD_EXT
L05 VDD_INT
L06 GND
L07 GND
L08 GND
L09 GND
L10 GND
L11 GND
L12 GND
Ball No. Pin Name
L13 GND
L14 GND
L15 GND
L16 VDD_INT
L17 VDD_EXT
L18 DAI0_PIN17
L19 GND
L20 DAI0_PIN20
M01 DMC0_A14
M02 DMC0_A15
M03 PD_09
M04 VDD_EXT
M05 VDD_INT
M06 GND
M07 GND
M08 GND
M09 GND
M10 GND
M11 GND
M12 GND
M13 GND
M14 GND
M15 GND
M16 VDD_INT
M17 VDD_EXT
M18 HADC0_VIN7
M19 HADC0_VIN5
M20 HADC0_VIN6
N01 DMC0_A11
N02 DMC0_A13
N03 DMC0_A12
N04 VDD_DMC
N05 VDD_INT
N06 GND
N07 GND
N08 GND
N09 GND
N10 GND
N11 GND
N12 GND
N13 GND
N14 GND
N15 GND
N16 VDD_INT
N17 VDD_EXT
N18 HADC0_VIN4
N19 HADC0_VIN3
N20 GND
Ball No. Pin Name
P01 DMC0_VREF
P02 DMC0_RZQ
P03 DMC0_A09
P04 DMC0_A10
P05 VDD_INT
P06 VDD_INT
P07 GND
P08 VDD_INT
P09 VDD_INT
P10 VDD_INT
P11 VDD_INT
P12 VDD_INT
P13 VDD_INT
P14 GND
P15 VDD_INT
P16 VDD_INT
P17 HADC0_VIN1
P18 HADC0_VIN0
P19 HADC0_VREFP
P20 HADC0_VREFN
R01 PD_06
R02 PD_07
R03 PD_08
R04 VDD_INT
R05 VDD_INT
R06 GND
R07 VDD_INT
R08 VDD_INT
R09 VDD_INT
R10 VDD_INT
R11 VDD_INT
R12 VDD_INT
R13 VDD_INT
R14 VDD_INT
R15 GND
R16 VDD_INT
R17 VDD_INT
R18 DMC0_BA0
R19 HADC0_VIN2
R20 VDD_HADC
T01 PD_05
T02 TWI0_SDA
T03 TWI0_SCL
T04 VDD_EXT
T05 GND
T06 VDD_DMC
T07 VDD_DMC
T08 VDD_DMC
Ball No. Pin Name
T09 VDD_DMC
T10 VDD_DMC
T11 VDD_DMC
T12 VDD_DMC
T13 VDD_DMC
T14 VDD_DMC
T15 VDD_DMC
T16 GND
T17 VDD_DMC
T18 DMC0_A02
T19 DMC0_A01
T20 DMC0_RESET
U01 DMC0_DQ15
U02 DMC0_DQ14
U03 TWI1_SDA
U04 GND
U05 TWI1_SCL
U06 VDD_EXT
U07 VDD_DMC
U08 VDD_DMC
U09 VDD_DMC
U10 VDD_DMC
U11 VDD_DMC
U12 VDD_DMC
U13 VDD_DMC
U14 VDD_DMC
U15 DMC0_BA2
U16 DMC0_WE
U17 GND
U18 DMC0_A06
U19 DMC0_A03
U20 DMC0_A00
V01 TWI2_SDA
V02 DMC0_DQ13
V03 GND
V04 PD_03
V05 PD_04
V06 PD_01
V07 PA_08
V08 PA_05
V09 PA_03
V10 PA_02
V11 PA_01
V12 PA_00
V13 SYS_RESOUT
V14 SYS_FAULT
V15 DMC0_CAS
V16 DMC0_RAS
Ball No. Pin Name
V17 DMC0_BA1
V18 GND
V19 DMC0_A04
V20 DMC0_A05
W01 TWI2_SCL
W02 GND
W03 DMC0_DQ12
W04 DMC0_DQ11
W05 DMC0_DQ09
W06 PD_02
W07 PD_00
W08 PA_07
W09 PA_06
W10 PA_04
W11 DMC0_DQ05
W12 DMC0_DQ04
W13 DMC0_DQ03
W14 DMC0_DQ02
W15 SYS_FAULT
W16 DMC0_ODT
W17 DMC0_A08
W18 SYS_BMODE1
W19 GND
W20 DMC0_A07
Y01 GND
Y02 DMC0_UDQS
Y03 DMC0_UDQS
Y04 DMC0_DQ10
Y05 DMC0_DQ08
Y06 DMC0_UDM
Y07 DMC0_LDM
Y08 DMC0_CK
Y09 DMC0_CK
Y10 DMC0_DQ07
Y11 DMC0_DQ06
Y12 DMC0_LDQS
Y13 DMC0_LDQS
Y14 DMC0_DQ01
Y15 DMC0_DQ00
Y16 DMC0_CKE
Y17 DMC0_CS0
Y18 SYS_BMODE0
Y19 SYS_BMODE2
Y20 GND
