48
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
8 /A1S nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693D
8 /F1N nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693F
8 /K1G nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693E
8 /L1G nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693G
8 /N1B nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693C
8 /N1G nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693C
8 /N1S nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693C
8 /U1B nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693B
8 /U1S nsp nsp PCB ASSY FRONT PCB ASS'Y COP11693B
9 nsp nsp BUFFER TAPE , HEMELON KHS1A032
10 00M27AW355010 00M27AW355010 LENS INDICATOR , POWER CGL1A216
11 /A1B nsp 00M27AW270040 BUTTON KNOB , POWER CBC1A146K92
11 /A1S nsp 00M27AW270240 BUTTON KNOB , POWER CBC1A146R6G13
11 /F1N nsp 00M27AW270140 BUTTON KNOB , POWER CBC1A146RFD4
11 /K1G nsp 00M27AW270140 BUTTON KNOB , POWER CBC1A146RFD4
11 /N1B 00M27AW270040 00M27AW270040 BUTTON KNOB , POWER CBC1A146K92
11 /N1G 00M27AW270140 00M27AW270140 BUTTON KNOB , POWER CBC1A146RFD4
11 /N1S 00M27AW270240 00M27AW270240 BUTTON KNOB , POWER CBC1A146R6G13
12 /A1B nsp nsp BRACKET BRACKET , POWER CMD1A493
12 /A1S nsp nsp BRACKET BRACKET , POWER CMD1A493
12 /F1N nsp nsp BRACKET BRACKET , POWER CMD1A493
12 /K1G nsp nsp BRACKET BRACKET , POWER CMD1A493
12 /N1B nsp nsp BRACKET BRACKET , POWER CMD1A493
12 /N1G nsp nsp BRACKET BRACKET , POWER CMD1A493
12 /N1S nsp nsp BRACKET BRACKET , POWER CMD1A493
14 /L1G nsp 00M27AW270140 BUTTON KNOB , POWER CBT1A877RFD4
14 /U1B nsp 00M27AW270030 BUTTON KNOB , POWER CBT1A877K92
14 /U1S nsp 00M27AW270230 BUTTON KNOB , POWER CBT1A877R6G13
15 nsp nsp BUFFER RUBBER , CUSHION KHG1A050
16 /A1B nsp 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /A1S nsp 00M243W057210 LEG FOOT , FRONT CKL2A042H46
16 /F1N nsp 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /K1G nsp 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /L1G nsp 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /N1B 00M243W057010 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /N1G 00M243W057010 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /N1S 00M243W057210 00M243W057210 LEG FOOT , FRONT CKL2A042H46
16 /U1B nsp 00M243W057010 LEG FOOT , FRONT CKL2A042H11
16 /U1S nsp 00M243W057210 LEG FOOT , FRONT CKL2A042H46
17 nsp nsp CHASSIS CHASSIS , BOTTOM CUA1A247
18 nsp nsp HOLDER HOLDER , PCB CHE170
22 /A1B nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695D
22 /A1S nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695D
22 /F1N nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695F
22 /K1G nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695E
22 /L1G nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695G
22 /N1B nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695C
22 /N1G nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695C
22 /N1S nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695C
22 /U1B nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695B
22 /U1S nsp nsp PCB ASSY MAIN PCB ASS'Y COP11695B
23 nsp nsp BRACKET BRACKET , TRANS CMD1A487
24 /A1B nsp 90M-TS002200R TRANSF. TRANS , POWER SR4500/N T901 CLT5W014ZE
24 /A1S nsp 90M-TS002200R TRANSF. TRANS , POWER SR4500/N T901 CLT5W014ZE
24 /F1N nsp 90M-TS002250R TRANSF. TRANS , POWER SR4500/F T901 CLT5W014ZJ
24 /K1G nsp 90M-TS002260R TRANSF. TRANS , POWER SR4500/K T901 CLT5W014ZH
24 /L1G nsp 90M-TS002270R TRANSF. TRANS , POWER SR4500/L T901 CLT5W014ZS
24 /N1B 90M-TS002200R 90M-TS002200R TRANSF. TRANS , POWER SR4500/N T901 CLT5W014ZE
24 /N1G 90M-TS002200R 90M-TS002200R TRANSF. TRANS , POWER SR4500/N T901 CLT5W014ZE
24 /N1S 90M-TS002200R 90M-TS002200R TRANSF. TRANS , POWER SR4500/N T901 CLT5W014ZE
24 /U1B nsp 90M-TS002180R TRANSF. TRANS , POWER SR4500/U T901 CLT5W014ZU
24 /U1S nsp 90M-TS002180R TRANSF. TRANS , POWER SR4500/U T901 CLT5W014ZU
