NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
COMPONENT DIG INPUT PCB (CUP11693-4)
COMPO IN BN13 nsp nsp CONNECTIVE CORD CWB2B907100EN
COMPO IN BN29 90M-YJ002800R 90M-YJ002800R JACK 3011 - DR12 - G KJP12GB143ZP
COMPO IN C601 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C602 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C603 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C604 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C605 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C606 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C607 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C608 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C609 nsp nsp CERAMIC CAP. 22PF 50V J HCBS1H220JCT
COMPO IN C610 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
COMPO IN C611 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMPO IN C612 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
COMPO IN C613 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMPO IN C614 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMPO IN C615 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMPO IN C616 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMPO IN C617 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMPO IN C618 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMPO IN C619 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMPO IN C620 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
COMPO IN C621 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
COMPO IN C622 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
COMPO IN C630 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMPO IN C631 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMPO IN C632 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMPO IN C633 nsp nsp CERAMIC CAP. 100PF 50V KB CCKT1H101KB
COMPO IN C634 nsp nsp CERAMIC CAP. 100PF 50V KB CCKT1H101KB
COMPO IN C635 nsp nsp CERAMIC CAP. 100PF 50V KB CCKT1H101KB
COMPO IN C636 nsp nsp CERAMIC CAP. 0.1UF 50V ZF CCFT1H104ZF
COMPO IN C637 nsp nsp CERAMIC CAP. 0.1UF 50V ZF CCFT1H104ZF
COMPO IN C638 nsp nsp CERAMIC CAP. 0.1UF 50V ZF CCFT1H104ZF
COMPO IN C639 nsp nsp CERAMIC CAP. 0.047UF 50V ZF CCKT1H473ZF
COMPO IN C640 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMPO IN IC61 90M-HC108940R 90M-HC108940R IC NJM2586M HVINJM2586MTE1
COMPO IN IC62 00MHC700400Z0 00MHC700400Z0 IC TC74HCU04AFN HVITC74HCU04AFN
COMPO IN J501 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J502 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J503 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J504 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J505 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J506 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J507 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J531 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J532 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J533 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J561 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J562 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J563 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J564 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J581 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J595 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J601 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J602 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J603 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J606 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J611 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J612 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J613 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J614 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN J621 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
